Description

The Aero Pure (AP90H) slim-fit exhaust fan offers a versatile solution for bathroom ventilation, designed to fit seamlessly into either 2 x 6 inch or 2 x 8 inch construction spaces. Equipped with a 13W, 2700K LED light pad, it provides warm natural lighting ideal for any bathroom setting. ETL/cETL listed for use in shower or tub/shower enclosures when connected to a GFCI circuit breaker, this fan ensures safety and compliance with electrical standards. Operating at 90 CFM, it effectively manages air volume while maintaining an ultra-quiet noise level of just 0.3 sones, exceeding minimum standards for continuous operation. Backed by a full six-year warranty, the fan features a permanently lubricated ball-bearing motor for long-lasting, quiet performance, emphasizing reliability and durability. For installation, it is recommended to enlist the expertise of a licensed professional to ensure proper setup and functionality.

Notice: Must be installed by a licensed professional

Features:

• 90 CFM output quickly clears your bathroom of moisture
• Ventilates rooms up to 90 sq. ft.
• At 0.3 sones of sound output, this ultra quiet fan will keep your bathroom quiet and peaceful
• Includes a 10W 3000K LED light that offers warm, natural illumination
• The integrated Humidity Sensor responds to increases in humidity above a user set point and automatically turns the fan off when the humidity falls below the set point
• Designed and approved for recessed installation in insulated ceiling or wall
• Slim Fit housing fits 2 x 6″ or 2 x 8″ construction
• Includes anti-vibration mounting brackets expandable to 24″ and detachable 4″ and 6″ round duct connector for easy installation
• Corrosion-resistant galvanized steel housing with built-in backdraft damper prevents outside air from entering the bathroom
• Approved for installation over a shower area when connected to a GFCI breaker
• Bath fan is certified for ASHRAE, ETL, HVI, and UL
• Covered under a 6 year limited manufacturer warranty

Product Technologies:

• LED Lighting: LED lights are very cost-effective and have an impressive lifespan. The brightness of an LED light is not determined by wattage (which is the energy required to light a product), but by lumens. Aero Pure’s LED light uses only 10Ws but provides 1100 lumens of “brightness” which is comparable to a traditional 75 W incandescent bulb. One 26W CFL bulb provides as much light as one 100W incandescent bulb and uses less energy than conventional incandescent bulbs. More light, less W’s.

• Slim Fit Design: Fits easily into tight spaces, making it perfect for remodels or new construction projects

Specifications:

• CFM: 90
• Sones: 0.3
• Bulb Type: LED
• Duct Size: 4″ Round, 6″ Round
• Grille Width: 13″
• Grille Length: 13″
• Housing Width: 10-1/2″
• Housing Length: 11-3/8″
• Housing Depth: 5-7/8″
• Amperage: 0.45A
• Voltage: 120V
• Wattage: 33W

Product Variations:

• AP90-S: 90 CFM 0.3 Sone Ceiling Mounted Energy Star Certified Bath Fan with Slim-Fit Housing
• AP90H-S: 90 CFM 0.3 Sone Ceiling Mounted Energy Star Certified Bath Fan with Humidity Sensor and Slim-Fit Housing
• AP90-SL: 90 CFM 0.3 Sone Ceiling Mounted Energy Star Certified Bath Fan with LED Lighting and Slim-Fit Housing
• AP90H-SL (This Model): 90 CFM 0.3 Sone Ceiling Mounted Energy Star Certified Bath Fan with Humidity Sensor, LED Lighting, and Slim-Fit Housing
