Description
Two keys will be shipped per lock. Three or more items keyed alike will ship a total of 6 keys
Double Cylinder Function: The deadbolt is thrown and retracted by a key from either side. As you will not be able to unlock this from the inside without a key, please check your local fire code to ensure this is allowed before purchasing.
Features:
- Exceeds criteria for BHMA Grade 3 certification
- Durable construction and high attention to detail
- Premium finish maintains its appearance over time
- Designed for both left and right hand door configurations
- Includes square corner, round corner, or drive-in latch faceplate
- Complies with standards of the Americans with Disabilities Act (ADA)
- Covered under Limited Lifetime Mechanical and 5 Year Finish Warranty
Specifications:
- Backset: Adjustable 2-3/8″ or 2-3/4″
- Cross Bore: 2-1/8″
- Edge Bore: 1″
- Door Thickness: 1-3/8″ to 1-3/4″
- Handing: Reversible Left or Right
- Height: 2-1/2″
- Projection: 1″
- Latch Faceplate: Round Corner, Square Corner or Drive-In
- Cylinder: 5 Pin KW1
- Material: Brass, Steel, Zinc
Product Variations:
- DBR2410: Single Cylinder Deadbolt
- DBR2420 (This Model): Double Cylinder Deadbolt
Dimensions and Measurements
| Backset | Adjustable 2-3/8″ or 2-3/4″, 2-3/8″, 2-3/4″ |
| Cross Bore | 2-1/8″ |
| Door Thickness | 1-3/8″, 1-1/2″, 1-5/8″, 1-3/4″ |
| Edge Bore | 1″ |
| Exterior Height | 2.5 in. |
| Exterior Projection | 1 in. |
| Exterior Width | 2.5 in. |
| Interior Height | 2.5 in. |
| Interior Projection | 1 in. |
| Interior Width | 2.5 in. |
Characteristics and Features
| Concealed Screws | No |
| Cylinder | 5 Pin KW1 |
| Cylinder Type | Double Cylinder |
| Function | Keyed Entry |
| Handing | Left, Reversible, Right |
| Interconnected | No |
| Keyway | KW1 |
| Latch Faceplate | Drive-In, Round Corner, Square Corner |
| Material | Steel, Zinc, Brass |
| Mortise | No |
| Panic Proof | No |
| Removable Core | No |
| Rosette Shape | Round |
| Solid Construction | Solid Brass |
| Theme | Transitional |
