Description

The Modine POR100 is an advanced oil fired unit heater that is both efficient and reliable. Capable of emitting 100,000 BTU/hr of heat, the POR100 has enough power to warm even very large areas. An efficient PSC fan motor powers the propeller while a two stage fuel unit ensures fuel pressure is always kept high. The unit heater uses advanced microprocessor based burner technology to provide an all-in-one tool for data readings, efficient fuel consumption, and automatic reset control.

Product Information:

Advanced Flame Retention Burner
• The flame retention burner on the POR100 produces a highly stable flame, giving the burner a 20 to 30 percent increase in combustion efficiency over non-flame retention burners.

Two Stage Fuel Delivery

• The fuel unit on the POR100 uses two distinct stages to ensure maximum fuel pressure during varying degrees of operation. This allows the unit heater a high degree of functionality even in high lift applications.

Permanent Capacitor Split Motor

• The permanent capacitor split motor design used for the propeller’s motor works together with high grade ball bearings to reduce motor energy consumption and maintenance needs.

Interrupted-Duty Ignition

• The sensors included in the ignition disable the igniter once a flame has been detected. This feature extends the life of the ignition system, reduces component noise, and reduces gas usage during the ignition process to an absolute minimum.

Beckett CleanCut Oil Pump

• The POR100 comes with a Beckett CleanCut pump. The cleaning operation of the burner cuts oil flow almost immediately after power to the motor is cut, resulting is less wasted oil and higher system life.

Modine Installation

• Installation by a professional installer is required by the manufacturer.

General Information:

• Product Category: Unit Heater
• Fuel Type: Oil
• Vent Type: Chimney
• Installation Type: Suspended

Performance:

• BTU Heating: 119,000
• Maximum BTU Input: 119,000
• Maximum Air Flow: 1890 CFM

Electrical Data:

• Voltage: 115V
• Electrical Phases: 1
• Frequency: 60 Hz

Dimensions:

• Pipe Inside Diameter: 8″
• Height: 35-1/4″
• Width: 27-1/2″
• Depth: 38-1/8″
• Product Weight: 324 lbs

Product Assurance:

• Certifications: UL
• Made in America
• Warranty: 2 Year Parts
