Description
Features:
- 6 7/8 inch ceiling opening with 1/2 inch and 3/4 inch knockouts
- Will maintain up to a one-hour fire rating when installed in a UL L500 series non-IC fire rated floor/ceiling assembly
- UL Classified to maintain fire ratings of 2 hours or less in all UL D200, G200, L200, D500, G500 and L500 series fire rated ceiling assemblies
- Trim-Lok® action forces trim to fit snugly against the ceiling
- Socket mounts to trim for optimum performance and consistent lamp position
- Covered under a 1 year limited manufacturer warranty
- Fiberglass gasket on bottom of frame to minimize heat transfer into ceiling cavity
- 6 pieces of UL classified fire resistant gypsum board attached to recessed housing
- Non-IC rated; insulation must be kept at least 3” away from housing
- Universal J-box with snap-out sides
Dimensions:
- Height: 9.1875″
- Depth: 9.5625″
- Width: 13.375″
Electrical Specifications:
- Bulb Base: Medium (E26)
- Number of Bulbs: 1
Dimensions and Measurements
| Cutout Size | 6.875 in. |
| Depth | 9.5625 in. |
| Height | 9.1875 in. |
| Trim Size | 6 in. |
| Width | 13.375 in. |
Characteristics and Features
| Airtight | No |
| Bulb Base | Medium (E26) |
| Housing Type | New Construction Housing |
| Light Direction | Down Lighting |
| Material | Steel |
| Number of Bulbs | 1 |
| Number of Light Source(s) | 1 |
| Shallow Ceiling Compatible | No |
| Sloped Ceiling Compatible | No |
