Description

Williams’ Direct-Vent Wall Furnace makes heating any home easy. The Direct-Vent model is attractive and economical with a slim design taking up minimal space. Safety is no worry with this furnace, having a matchless pilot igniter and sealed combustion chamber requiring no inside air. The scratch-resistant coating can blend in nicely with any homes decor.

Product Information:

Space-Saving Size
• The direct vent model is a low-profile furnace that can fit in just about any space. Having a unique wall mount design, this furnace requires no floor space.

No Electricity Needed

• During power outages, you have a lot to worry about, but your furnace won’t be one. The Direct-Vent furnace requires no electricity for operation.

Sealed Combustion

• Rather than using indoor air to fuel combustion, the Williams direct vent pulls intake air directly from the outdoors. This means the heat your furnace generates isn’t fed back into the system, maximizing efficiency.

Easy Installation

• The Williams Direct Vent furnace mounts directly on the outside-facing wall. Venting is accomplished through a single 9″ opening to the outdoors and vent materials that will accommodate most installations are included.

Product Includes

• Williams Direct-Vent Furnace
• All Vent Materials Needed for a 9″ Thick Wall

General Information:

• Product Category: Wall Mounted Heater
• Fuel Type: Natural Gas
• Vent Type: Rear (Direct Vent)
• Installation Type: Wall Mount
• NG Converstion Kit: Available
• Control Type: Knob
• Installation Location: Indoor

Performance:

• AFUE Rating 66%
• BTU Output: 30,000
• High Fire Input: 30,000 BTU
• High Fire Output: 21,000 BTU

Dimensions:

• Gas Connection: 1/2″
• Height: 28″
• Width: 32-1/8″
• Depth: 10-1/4″
• Product Weight: 90 lbs

Product Assurance:

• Certifications: CSA
• Made in America
• Warranty: 1 Year Parts and 10 Year Heat Exchanger
